Schlumberger RF-6 Radial Drilling & Tapping Machine

Radial Drilling and Tapping Machine made by Schlumberger (France) in excellent working condition. The model of the machine is RF-6 and the Drilling Capacity is 50 mm. Due to its unique design the machine is suitable for small sized jobs as well as large sized jobs and as compared to a normal design radial drill machine the setting time is comparatively lesser in this machine. The machine can do Drilling as well as Tapping operations. The technical details are as follows -

Make - Schlumberger (France)

Model - RF 6

Drilling Capacity - 50 mm

Spindle Diameter - 90 mm

Spindle Speeds - 35 rpm to 1800 rpm

Spindle Taper - BT-40

Max. Height between Spindle to Table Top - 940 mm

Min. Distance between Spindle Center to Pillar - 130 mm

Max. Distance between Spindle Center to Pillar - 900 mm

Table Size - 1000 mm x 650 mm

Vertical Clamping Table Size - 800 mm x 800 mm

Spindle Feed Rate - 0.06 mm/min to 0.60 mm/min

Spindle Feed Travel - 350 mm

Head Rotation - 360 degree

Tool Clamping - Automatic ; Hydraulic

Arm Clamping Type - Automatic ; Hydraulic

- With Automatic Tapping Feature.

- Complete with many Tool Holders & Coolant Pump.

- Machine is in excellent working condition.
