Hurth Germany LFV-3 Vertical Automatic Slot Milling Machine

Automatic Vertical Slot Milling Machine manufactured by Hurth (Germany), Model LFV-3, available in excellent working condition. This is a High-Production Automatic Milling Machine designed for machining keyways, splines, slots, notches, grooves, and similar profiles. The machine features Automatic Depth Feed through the spindle, enabling efficient, accurate, and repeatable machining operations. It also features Automatic Longitudinal Feed of the Table, allowing the machining of longer slots and profiles. The machine has a Maximum Slot Width of 50 mm and a Maximum Slot Length of 240 mm + Tool Diameter using the reciprocating motion of the Milling Head alone, and up to 790 mm + Tool Diameter when the Table Travel is also utilised. The technical details are as follows -

Make - Hurth (Germany)

Model - LFV-3

Max. Slot Width - 50 mm

Max. Slot Length - 240 mm + Tool Diameter

Max. Slot Length using Table Travel - 790 mm + Tool Diameter

Max. Slot Depth - 110 mm

Table Size - 1240 mm x 350 mm

Centre Height of the Dividing Head - 130 mm

Distance between Centers - 550 mm

Longitudinal Feed Travel of Table (Automatic) - 550 mm

Cross Travel of Table (Manual) - 250 mm

Spindle Speed Range - 90 to 1000 RPM

Spindle Taper - ISO-40

Milling Head Stroke Rate - 1.4 to 22.4 strokes/min

Automatic Depth Feed Rate - 0.05 to 0.50 mm/stroke

- High-Production Automatic Operation with Automatic Depth Feed.

- Suitable for machining Keyways, Splines, Slots, Notches, Grooves, and similar profiles.

- Equipped with DRO for Longitudinal Table Travel.

- Complete with Tool Holder, Collet Holder, Collets, and other accessories.

- Machine is in excellent working condition.
